Replacement Part List

118791_1113 6-11
54" Deck Pulleys & Spindles
NOTES:
1. Torque to 73 ft-lbs.
2. Torque to 30 ft-lbs.
INDEX NO. PART NO. QTY. DESCRIPTION
1 781567 3 NT .500-13 NL G5
2 767962 3 FW .531 X 1.063 X .090 SAE
3 604792 1 IDLER PULLEY, 5.00" O.D.
4 604251 7 NT .312-18 HX NL JAM G2 ZN
5 604252 6 FW .340 X .675 X .035 ZN
6 604110 2 SPRING TENSIONER ANCHOR
7 604291 1 IDLER SPRING
8 604791 1 IDLER SLED
9 604790 2 IDLER SLIDE
10 604253 1 CB .50-13 X 2.00 STD ZN
11 705954 3 CS .500-13 X 1.25 HX G5 ZN
12 798603 3 FW .515 X 1.65 X .125 HD ZY
13 604661 6 PULLEY SPACER
14 604664 3 PULLEY
15 054502 12 NT .375-16 HX G5 ZNY
16 767954 24 FW .406 X .812 X .060 SAE
17 604231 2 IDLER PULLEY, 5.00" O.D.
18 005116 12 CS .375-16 X 1.375 HX G5
19 601804 3 SPINDLE ASSEMBLY
20 604254 2 CB .50-13 X 2.50 STD ZN
21 083147 7 CB .312-18 X .620 G5 ZN
22 768523 1 FW .343 X .687 X .051/.080H
