Replacement Part List

118791_1113 5-3
Engine, Kawasaki FR651V/FR691V/FR730V
NOTES:
1. Supplied with the engine.
2. Torque to 45–48 ft-lbs. Replace (do not reuse) the cap screw if it’s
removed or loosened. Use only hand tools to install this fastener.
3. Torque to 30–35 ft-lbs. Replace (do not reuse) the cap screw if it’s
removed or loosened. Use only hand tools to install this fastener.
INDEX NO. PART NO. QTY. DESCRIPTION
1N/A1KAWASAKI FR651V/FR691V/FR730V ENGINE
2 604369 1 O-RING
3 604350 1 OIL DRAIN VALVE
4 604463 12" OIL DRAIN HOSE
5 604016 1 MUFFLER
6 016899 1 NT .375-16 HX FLK ZNYC
7 118238 1 CLUTCH ANCHOR
8 767954 5 FW .406 X .812 X .060 SAE
9 036244 1 CS .375-16 X 1.00 HX G5
10 602580 4 CS .375-16 X 1.25 HX G5 P85
11 000331 4 WIRE TIE
12 604712 1 STUB SHAFT PUMP PULLEY
13 604713K 1 CLUTCH KIT
14 602680 1 FW .453 X 1.12 X .119 HRD
15 604721 1 CS .437-20 X 5.00 HX G5
16 791251 1 CLUTCH HARNESS PIGTAIL
