Replacement Part List
Table Of Contents
118791_1113 3-13
Steering Cover Assembly
NOTES:
INDEX NO. PART NO. QTY. DESCRIPTION
1 604452 2 CS .250-20 X 2.00 HX FLTHD
2 768515 4 FW .281 X .625 X .051/.080 HD ZN/YL
3 117540 2 DRIVE STRAIGHT STOP
4 808477 4 1/4-20 THREAD RIVET NUT
5 055939 2 CS .250-20 X .75 HX G5
6 601822 2 NUT PLATE .420 CENTERS
7 781211 2 PUSH BUTTON SWITCH
8 086660 3 NT .375-16 HX ZY NL
9 552415 1 STEERING COVER (WITH DECALS)
10 781708 2 CS .500-13 X 4.25 HX G5
11 604288 2 STEERING SPACER
12 604300 1 LS STEERING BOX
13 768523 8 FW .343 X .687 X .051/.080H
14 058776 4 NT .312-18 HX ZY NL
15 604179 2 BRAKE ROD
16 765339 4 BUSHING
17 116142 1 LS BRAKE BELLCRANK
18 781567 2 NT .500-13 HX G8 ZY NL
19 063198 4 CS 10-24 X .75 HX FLK ZN
20 005108 2 CS .375-16 X 3.50 HX G5 Z
21 604299 1 RS STEERING BOX
22 116141 1 RS BRAKE BELLCRANK
23 781153 4 BUSHINGS
