Replacement Part List

118791_1113 3-7
Transmission Assembly
NOTES:
INDEX NO. PART NO. QTY. DESCRIPTION
1 058776 2 NT .312-18 HX NL G5
2 768523 6 FW .343 X .687 X .051/.080H
3 601051 2 OVERTRAVEL SPRING
4 601131 2 SPRING
5 604667 2 ROD BRAKE ACTUATOR
6 601219 2 FITTING, 90 - 9/16 SAE
7 604709 1 LS TRANSMISSION
8 056036 2 CS .375-16 X 2.25 HX G5
9 767954 4 FW .406 X .812 X .060 SAE
10 601001 4 SPRING CLAMP
11 787713 47" HOSE, 0.50" LOW PRESSURE
12 000331 2 WIRE TIE
13 086660 2 NT .375-16 NL G5
14 118942 1 CROSS BRACE
15 604708 1 RS TRANSMISSION
16 055939 2 CS .250-20 X .75 HX G5
17 109203 1 LS BRAKE SPRING LINK
18 016816 2 NT .250-20 HX FL LK ZNY
19 109202 1 RS BRAKE SPRING LINK (NOT SHOWN)
TRANSMISSION TO TANK HOSE LENGTHS
28" LS TRANSMISSION
19" RS TRANSMISSION
A
B
