Replacement Part List
Table Of Contents
118791_1113 3-3
Hydraulic System
NOTES:
1. Torque to 17 ft-lbs.
INDEX NO. PART NO. QTY. DESCRIPTION
1 710087 4 CS .312-18 X 2.50 HX G5
2 601887 1 CB .375-16 X 2.75 STD ZN
3 043067 4 CS .312-18 X 3.00 HX G5 Z
4 016899 3 NT .375-16 HX FLK ZNYC
5 603907 1 DRIVE BELT
6 604714 1 IDLER SPACER
7 116287 1 IDLER ARM
8 712893 1 FW .406 X 1.25 X .12 HRD Z
9 086660 1 NT .375-16 NL G5
10 080655 1 CS .375-16 X 1.50 HX G5
11 767954 2 FW .406 X .812 X .060 SAE
12 604491 1 PULLEY 2.0" IDLER
13 054502 2 NT .375-16 HX G5 ZNY
14 604490 1 SPRING
15 604487 1 CS .375-16 X 2.5 FULTH
16 706549 2 HP .080D X 1.19
17 118310 2 TOW VALVE LINK
18 768523 16 FW .343 X .687 X .051/.080H
19 058776 8 NT 0.312-18 NL G5
