Replacement Part List

118791_1113 2-9
Battery
NOTES:
1. When performing service on the mower, disconnect the battery ground
cable and do not reconnect it to the battery until the engine is ready to
be started.
INDEX NO. PART NO. QTY. DESCRIPTION
1 604178 1 TIE DOWN STRAP
2 604465 2 CS 0.250-20 X 7.50 HX G5
3 768515 2 FW .281 X .625 X .051/.080 HD ZN/YL
4 771428 1 RED BATTERY CABLE BOOT
5 024927 2 NT .250-20 HX G5 ZNYC
6 029868 4 LW .250 INT-EXT TOOTH Z
7 055939 2 CS .250-20 X .75 HX G5
8 000331 2 WIRE TIE
9 601982 2 CN .250-20 X .15 MAX THK
