Installation & Operation Manual REV.
IGIP-DBP, DBRP 01,03-0210 General Instructions Table Of Contents THIS BOOKLET CONTAINS INFORMATION ON: DBP, DBRP 01,03 General Instructions ................................................. 2 Cut & Plan Views ....................................................... 3 Installation ................................................................. 4 Leveling ................................................................................................................ 4 Splash Guard .......................
Rev.0210 Cut & Plan Views Optional Ref. High Center Divider and Ref. Lighted Shelves 16" 26 1/8" Optional Base Display 35 1/4" 26 1/8" 30" 30" 11" 15 3/4" 38 1/2" 70 1/4" Optional Base Display 15 3/4" DBRP-03 Shown with Optional Ref. High Center Divider and Refrigerated Lighted Shelves DBP-03 Standard Section Produce Scale = 3/8” Scale = 3/8" 20 1/8" Variable Drain 24" X 24" 26 1/8" 701/4" 40" Mech. stub-up area Elec. Straight Racks 9" Optional Step Racks 4" 7 3/8" 4" Ref.
IGIP-DBP, DBRP 01,03-0210 9" Straight Racks Optional Step Racks 4" 7 3/8" 14 7/8" 8'-1" 10'-6 3/4" 4" 4" 26 1/8" 26 1/8" Straight Racks 20 1/8" 20 1/8" Cut & Plan Views Optional 9" Step Racks 4" 7 3/8" 14 7/8" 6'-11 1/2" 9'-4 1/8" 15 7/8" DBRP 15 7/8" DBRP Crown Section Scale = 1/4" Octagon Section Scale = 1/4" 3'-10 1/2" 18" 5’-9 1/2" 18" Mech. stub-up area Center Display Mech.
Rev.0210 Installation (cont.) SETTING AND JOINING 6. Slide second case up to first case snugly.Then level second case to the first case so glass front, bumper and top are flush. 7. Apply bead of silicone to side of either half of case (if case is built in two pieces). Also apply silicone to seam between overhead light tubes. 8. Slide second half up to first case snugly.To compress silicone at joint, use two Jurgenson wood clamps to pull the inside of the bulkheads together.
IGIP-DBP, DBRP 01,03-0210 Plumbing WASTE OUTLET AND P-TRAP The waste outlet is located off the center of the case on one side allowing drip piping to be run lengthwise under the fixture. A 1-1/2" P-trap and threaded adapter are supplied with each fixture. The P-trap must be installed to prevent air leakage and insect entrance into the fixture. 3. 4. NOTE: PVC-DWV solvent cement is recommended. Follow the manufacturer’s instructions. ACCESS PANELS 5.
Rev.0210 Refrigeration REFRIGERANT TYPE to meet conditions present at your location. The standard refrigerant will be R-22 unless otherwise specified on the customer order. Check the serial plate on the case for information. ACCESS TO TX VALVES & DRAIN LINES The refrigerant line outlets are located under the case. Locate first the electrical box, the outlets are then on the same side of the case but at the opposite end. Insulate suction lines to prevent condensation drippage.
IGIP-DBP, DBRP 01,03-0210 Electrical control panel to the merchandisers is required for refrigeration thermostats. Most component amperes are listed in the “Case Specs” section, but always check the serial plate. WIRING COLOR CODE GREEN PURPLE ORANGE YELLOW RED / BLACK BLACK / WHITE BROWN GROUND ANTI-SWEAT LIGHTS RECEPTACLE T-STAT /SOLENOID 230V T-STAT / SOLENOID 115V FAN MOTORS BALLAST LOCATION Ballasts are located within the access panel that runs the length of the rear of the case.
Rev.0210 User Information IMPORTANT STEPS STOCKING Improper temperature and lighting will cause serious product loss. Discoloration, dehydration and spoilage can be controlled with proper use of the equipment and handling of product. Product temperature should always be maintained at a constant and proper temperature. This means that from the time the product is received, through storage, preparation and display, the temperature of the product must be controlled to maximize life of the product.
IGIP-DBP, DBRP 01,03-0210 Maintenance ELECTRICAL PRECAUTIONS Cypress, CA. 90630 T-5 BULBS Please note:T-5 lights must be turned off and on after bulb replacement. BEFORE SERVICING – Always disconnect electrical power at the main disconnect when servicing or replacing any electrical component This includes (but not limited to) Fans, Heaters, Thermostats, and Lights. EVAPORATOR FANS The evaporator fans are located at the center front of these merchandisers directly beneath the display pans.
Rev.0210 Electrical and Refrigeration Specifications LENGTH TEMPERATURE AVG PROD DISC TMP TMP BTU REQ’D PER FT. EVAP TMP 750 18° DISCHG. AIR T-STAT/ VELOC CUT IN @FPM SETTINGS FAN SIZE & NUMBER OF MOTORS DEFROST FREQ. & DURATION Forced 8" x 10° Air (6) 50 min. (2) 1.98 3.6 Forced Air Forced Air Forced Air Forced Air Forced Air Forced Air 8" x 10° (6) 8" x 10° (7) 8" x 10° (2) 8" x 10° (3) 8" x 10° (4) 8" x 10° (5) 50 min. (3) 50 min. (3) 50 min. (2) 50 min. (2) 50 min. (2) 50 min. (2) 1.
MOTOR 8' MOTOR 12' MOTOR 14' 12 Hussmann Corporation 13770 Ramona Avenue Chino, CA. 91710 (909)-590-4910 Lic.#: 644406 Lithonia self contained Ledge Lights (Optional) (No. of lamps varies with case length) BALLAST B-232 No. Description: Revisions: B B B 16' Orange MOTOR BALLAST B-232 Lighted Shelves (Optional for DBRP-03 case only) (No. of lamps varies with case length) MOTOR 10' Brown 20' Date: By: MOTOR 24' Drawn By: Abraham C.
B B B Lic. #644406 Hussmann Corporation 13770 Ramona Avenue Chino, Ca. 91710 909-590-4910 Orange Light Switch (No. of lamps varies with case length) Ledge Lights (Optional) Lithonia self contained B B B 3 2 1 Description : Revisions : No. Brown MOTOR MOTOR 8' MOTOR MOTOR MOTOR General Grounding Area 12' MOTOR Computer Date : By : MOTOR MOTOR Case Controller MOTOR 20' Next Assembly : Date : X 10/23/95 Adrian E.
S EEV TXV (Optional) F17T8 - SPX41 MOTOR Ballast Ballast Lic. #644406 Hussmann Corporation 13770 Ramona Avenue Chino, Ca. 91710 909-590-4910 Field Connections between both sections B232I120 MOTOR 3 2 1 No.
Rev.0210 Appendices APPENDIX A. – Temperature Guidelines Refrigerated tions and recommendations provided by the manufacturer for the installation of each individual type refrigerator. 1.2 Refrigeration piping should be sized according to the equipment manufacturer’s recommendations and installed in accordance with normal refrigeration practices. Refrigeration piping should be insulated according to the manufacturer’s recommendations. 1.3 A clogged waste outlet blocks refrigeration.
IGIP-DBP, DBRP 01,03-0210 potentially hazardous food. 1.1 The following recommendations are made for the purpose of arriving at easily taken and understood data which, coupled with other observations, may be used to determined whether a display refrigerator is working as intended: a) INSTRUMENT – A stainless steel stem-type thermometer is recommended and it should have a dial a minimum of 1 inch internal diameter.
Rev.0210 d) Care must be taken when cross merchandising products to ensure that potentially hazardous vegetable products are not placed in non refrigerated areas. e) Display and storage equipment doors should be kept closed during periods of inactivity. f) Minimize the transfer time of perishables from storage to display. g) Keep meat under refrigeration in meat cutting and processing area except for the few moments it is being handled in processing.
IGIP-DBP, DBRP 01,03-0210 18
Rev.0210 Limited Warranty This warranty is made to the original user at the original installation site and is not transferable. Hussmann merchandisers are warranted to be free from defect in material and workmanship under normal use and service for a period of one (1) year from the date of original installation (not to exceed fifteen (15) months from the date of shipment for the factory). Hussmann Impact Modular Coils are warranted for a total of five (5) years based upon the above criteria.
IGIP-DBP, DBRP 01,03-0210 Service Record Last service date: By: /Chino The MODEL NAME and SERIAL NUMBER is required in order to provide you with the correct parts and information for your particular unit. Additional copies of this publication may be obtained by contacting: Hussmann® Chino 13770 Ramona Avenue • Chino, California 91710 (909) 628-8942 FAX (909) 590-4910 (800) 395-9229 They can be found on a small metal plate on the unit. Please note them below for future reference.
