User's Manual

25



Diagnostics
TheDiagnosticsmenuallowsoperationandtestofdecoderfunctions.
FromtheMainMenu,movethepointertoDiagnosticsandpressNext3.
TurnStationOn/Off:TheICD‐HPcanturnindividualstationoutputsonand
offfordiagnosticpurposes.Thisfunctiononlyworkswithdecoderswired
into
thetwo‐wirepath,andwillnotoperatewhenpoweredbytheleadsfromthe
ICD‐HP!
Connectadecoderwiththeprogrammingcup.MovethepointertotheTurn
StationOn/Off,andpressNext3.
TheICD‐HPwillfirstconnecttothedecoder,anddisplaythefirststationoutput.Ifthedecoderisamulti‐stationdecoder,
usetheleftandrightarrowbuttonstomovetothestationtoturnonoroff.
Press+toturnastationon.Thestationwillrunforapproximately1minuteifrunningalone,or12minutesifanother
stationisrunningfromthecontroller(seeImportantNoteinthissection).TheStatewillchangefromOfftoOnaftera
fewseconds.
TURN STATION ON/OFF
----------------------
Output #: 1
Station #: ###
Serial #: ########
State: xxx
◄/► To Change Output #
+ On / - Off
