Light Kit

Make sure the light kit assembly is securely attached to the

upper switch housing. Failure to properly secure all three

assembly screws could result in the light xture falling.

Connect the plugs from the upper and

lower switch housings. Make sure to

line up the colored markings on the

connectors.

Align the keyhole slots in the light kit

housing with the two screws. Make sure

all the wires from the fan and the light kit

are snug inside the center of the light kit,

not pinched in between the upper switch

housing and the light kit or hanging out

of the sides.

Install the three switch housing

assembly screws found in the bag.
