User's Manual

Thuraya IP Voyager User Guide 39
Specification
Physical Characteristics
Weight (BDU)
2.2 kg
Weight (ADU)
2.0 kg
Size (BDU)
46 mm x 281 mm x 233 mm
Size (ADU)
252mm x 119mm
Packet Data Services
Streaming IP
384 kbps
Standard IP
444 kbps
Environmental
Operating Temperature
-25°C to +55°C
Storage Temperature
-40°C to +80°C
Operating Humidity
95% RH at 40°C
Mechanical Vibration
200-2000 Hz, 0.3 m²/s³ MIL-Spec 810B
Unpacked Drop
0.5m (cosmetic damage only)
Ingress Protection (ADU)
IP56
Compliance and certifications
CE, EMC 301 444, 301 489, IEC 60950
External Power
Main power input
10-32VDC
Maximum current
12A
Interfaces
Connectors
4 Ethernet (PoE-IEEE 802.3af standard)
User Interface
Web-based graphical user interface
accessible via standard web browser
External Connector
Thuraya Satellite tracking antenna
HN221(Land-mobile)
WLAN Connectivity
IEEE 802.11 b/g/n standard with:
- WEP, WPA and WPA2 encryption
- SSID broadcasting control
- MAC address filtering
- DHCP
