Mobile Printer MT800 User Manual (Rev.2.0) Manufacturer: Xiamen Hanin Electronic Technology Co., Ltd. Add: No.96, Rongyuan Road, Tong'an District, Xiamen, China, 361100 Web: www.hprt.
Statement This manual content may be altered without permission, and Xiamen Hanin Electronic Technology Co., Ltd. reserves the rights to make changes without notice in technology, spare parts, hardware and software of the products. If more information is needed about the products, please contact Xiamen Hanin Electronic Technology Co., Ltd. Without any written permission from the company, any section of this manual is prohibited to be copied or transferred in any form.
Important Safety Instructions Please read this chapter carefully before using the printer! Using the Printer 1. Water or other liquid should not spill into the printer, also the printer should not be expose to the rain, or else may cause printer damage. 2. Do not open the printer cover while the printer is printing, otherwise the printer may work improperly. 3. Too high(40℃)or too low(0℃) temperature will lead to the decrease of print quality. 4.
Battery Safety Precautions Ignore the following instructions may cause battery overheating, fire, explosion, damage and/or performance, and reduced product life. 1. Be sure to use the specified battery and power charger provided by our company, do not disassemble the printer to replace the non-official battery, or may cause fire, explosion or damage to the printer. 2. Do not allow water, sea water from entering or leaking into the battery.
Other Precautions The copyright for this user manual and various other manuals is property of our company. Any copying or conversion into electronic form and saving of this material without the express written permission is strictly prohibited. Use of the information contained in this manual is not subject to any patent liability. This manual has been prepared with utmost care and attention to detail but may contain certain errors and/or omissions.
CONTENTS 1. Product Introduction........................................................................................................................ 1 1.1 Introduction............................................................................................................................. 1 1.2 The main Features................................................................................................................... 1 1.3 Packing List..........................................................
9. Mobile Utility Tool.......................................................................................................................... 51 9.1 Operating System(OS) Environment......................................................................................51 9.2 Utility Tool Preparation..........................................................................................................51 9.3 Using Utility Tool................................................................................
MT800 User Manual 1. Product Introduction 1.1 Introduction HPRT A4 Mobile Printer, print anytime and anywhere. Virtual will be transformed into reality, making mobile office a new trend. The distance between home and office will be shortened, and the working place will no longer be limited. MT800 supports ribbon with RFID authentication to ensure HPRT’s original high quality supplies. HPRT, print your beautiful world. 1.2 The main Features 1.Perfectly portable for quality A4 printing 2.
MT800 User Manual 1.4 Appearance and Component Front Left Note: indicates Bluetooth function. Inner Note: Out-of-paper sensor and paper feed position sensor: Detecting whether there is paper or not and whether the paper offset occurs during the paper feeding process.
MT800 User Manual 2. General Specification 2.1 Printer Specification Table 2-1 General Specification Printing Parameter Paper Item Printing Method Printing Speed Printing Width Printing Density Printing protocol Type Width Thickness Ribbon Specification Sensors Communicati Standard on Interface Type Battery Voltage Capacity Input Power Output Reliability TPH life RAM Memory Flash Dimension (L×W×H, mm) Weight Certificates Parameter Direct thermal/Thermal transfer printing MAX.
MT800 User Manual 2.2 Media Specification Paper type Paper width Paper thickness A4 paper 210mm 60-90µm 2.3 Ribbon Specification Ribbon Parameter Width 215mm Length 14m Diameter 14.5mm 2.4 Dimension • Dimension: 310.5(L)×63.5(W)×40.
MT800 User Manual 3. Installation and Use of Printer 3.1 Open Top Cover 1. Press the [PUSH] button of both sides at the same time, then lift the printer cover upward. 3.2 Loading Ribbon 1. Hold the left and right wings of the ribbon by your hands, then align it to the printer per the arrow direction and press it down. Note: To avoid errors when loading the ribbon, please make sure that the arrow direction marked on the ribbon module align to the printer.
MT800 User Manual 2. Rotate the ribbon rewind wheels of both left top and lower right (or right top and lower left) towards the center simultaneously to make it smooth. 3. Press down the cover by hands until it clicks into place. 3.3 Loading Paper 1. Make sure the ribbon is properly loaded, hold down the power button for a few seconds, and then release it when the printer is turned on. 2. Put the paper into the paper inlet in parallel.
MT800 User Manual 3.4 Removing Paper Note: Don’t pull the paper out forcefully while the printer cover is closed, or it may damage the printer. Please remove the paper as follows. 1. Press the [PUSH] button of both sides at the same time, then lift the printer cover upward. 2. Remove the paper. 3.5 Printing Operation Please make sure that the printer is powered on, and has loaded ribbon and paper. (Refer to 3.2 and 3.3) 3.5.1 From Mobile Phone 1.
MT800 User Manual Note: For APP operation, please subject to the actual situation. 3.5.2 From Computer 1. Connect the printer to the computer via Bluetooth/USB, then install the printer driver on the computer. The driver download address: http://www.hprt.com/Downloads.html USB connection Bluetooth connection 2. Install the driver: please refer to “7. Windows Driver” and install the printer driver for MT800 on the computer. 4.
MT800 User Manual 4. Partial Component Description 4.1 Button 1. Power Button ①Turn On In the sate of power off, hold down the power button for about 3 seconds and the printer will be on. ②Turn Off In the state of power on, hold down the power button for about 3 seconds and the printer will be off. ③Print Self Test In the sate of power on, continuously press the power button for 3 times, the printer will print the self-check page. 2.
MT800 User Manual 4.2 LED Indicator and Buzzer MT800 has two LED indicators, which are front strip lamp and side pinhole lamp. 1. Front Strip Lamp The front strip lamp indicates the status of printer. The status is divided into four categories: behavior indication (red, green, white), charging indication (green), abnormal indication (red), and printing indication (white).
MT800 User Manual ④Behavior status Status LED (Red, Green, White) Turn on Flash a round Firmware upgrade Alternating flash Turn off Flash a round 2. Side Pinhole Lamp The side pinhole lamp is a blue monochrome lamp, indicating the connection status of the printer.
MT800 User Manual 5. Troubleshooting Your printer is very reliable, but occasionally problems may occur. This chapter provides information on some common problems you may encounter and how to solve them. If you encounter problems that you can not resolve, contact your dealer for assistance. 5.
MT800 User Manual 5.
MT800 User Manual 6. Clean Printer 6.1 Cleaning Head Printing quality might be degraded by dust, foreign substance, adhesive substance, or other pollution materials stuck in the printer head or inside the printer. When dirty, clean the print head as follows: ※ Notes: 1. Make sure to turn the printer power off prior to cleaning. 2. Open the paper cover and ribbon assembly, and remove the paper and ribbon. 3.
MT800 User Manual 7. Windows Driver 7.1 Operating System (OS) Environment The following operating systems are supported for usage. Microsoft Windows 10 (32 bit/64 bit) Microsoft Windows 8 (32 bit/64 bit) Microsoft Windows 7 SP1 (32 bit/64 bit) Microsoft Windows Vista SP2 (32 bit/64 bit) Microsoft Windows XP Professional SP3 (32 bit) Microsoft Windows Server 2012(64 bit) 7.2 Windows Driver Preparation Driver download URL: http://www.hprt.com/Downloads.
MT800 User Manual 7.3 Windows Driver Installation Notes: Under different operating system and different type of driver, the screen has slight difference. Please operate it according to the tips. Take HPRT MT800 (Windows 7) as example. 1. Double click Windows Driver. 2. Choose “English” and click “OK”. 3. Choose “I accept the agreement”, then click “Next”.
MT800 User Manual 4. Click “Next”. Note: If printer is already connected with computer by USB port, it only needs to click “Install”, then it will be installed automatically. Otherwise, proceed to the next step.
MT800 User Manual 5. Choose the matched type and port (USBxxx is for USB port, COMx is for serial port, LPTx is for parallel port). Choose the type of driver, port, such as “MT800”, “USB” as port. Click “Next”.
MT800 User Manual 6. Click “Finish”, the driver is installed successfully. 7. After installation, the icon will be found in “Start”→ “Devices and Printers”.
MT800 User Manual Special Instructions: If the driver has been installed before connecting USB cable, the port may be inconsistent, solve it by the following steps. Method One: Connect the printer to the computer via USB cable, and install the driver again. Method Two: 1) Right click the computer icon, choose “Properties” --- “Device Manager” --- “Universal Serial Bus controllers” --- “USB Printing Support ”, as shown below.
MT800 User Manual 2) Double click “USB Printing Support”, then click “Details”, choose “Bus relations” for property to see the port number. It is “USB001” as shown below.
MT800 User Manual 3) Click “Start" → “Devices and Printers”. Right click “HPRT MT800” and choose “Printing properties”. Click “Ports”, select “USB001” and click “Apply”. Then the port will be modified.
MT800 User Manual 7.4 Using Driver via Bluetooth Note: PC Bluetooth connection only support with Windows system currently, take Windows 7 for example below. 1. Turn on the printer. 2. Turn on the computer. The Bluetooth icon will show at the lower right of the screen. If the computer is not configured with Bluetooth function, you need to insert a Bluetooth Dongle into its USB connector. 3. Right click the icon, choose "Add a Device".
MT800 User Manual 4. Find the corresponding printer, click “Next”. 5. Add a printer successfully as shown in the figure. The printer takes MT800-140C for an example.
MT800 User Manual 6. Click “Start" → “Devices and Printers”. Right click “MT800-140C” and choose “Properties”. 7. In “MT800-140C Properties”, choose“Services” and find the corresponding port. As shown in the figure, the port of MT800-140C is COM3.
MT800 User Manual 8. Install MT800 Windows driver program on the computer (please refer to “7.3 Windows Driver Installation). 9. After installing the driver, find the icon of “HPRT MT800” in “Devices and Printers”, right click “Printer properties”.
MT800 User Manual 10. Click “Ports” , choose “COM3” as driver port, click “Apply”. Note: If “COM3” has been selected as printer driver port during the driver installation, ignore this step.
MT800 User Manual 11. Click “Print Test Page”.
MT800 User Manual 12. If the printer can print the test page, it will pop up the dialog box below. If it failed to print, please check if Bluetooth is connected or Bluetooth connection port is occupied.
MT800 User Manual 7.5 Detailed Windows Driver Setting 7.5.1 Printing Preferences 1. Click “Start" → “Devices and Printers”. Right click “HPRT MT800” and choose “Printing preferences”.
MT800 User Manual 2. According to the different needs, choose “Paper”/“Offset”/“Rotate”/“Effect”.
MT800 User Manual • Click “Manager”, add or delete paper: • Set “Horizontal” or “Vertical” offset: 32
MT800 User Manual • Set “Rotate”, “Effect”, e.g.
MT800 User Manual • Set “Media Type”: • Set “Enhance Mode”: 34
MT800 User Manual 13.Click “Watermark”. Set watermark to print.
MT800 User Manual 14.Click “Halftone” to set the halftone. 15.After setting, click “OK” to save it.
MT800 User Manual 7.5.2 Printer properties 1. Click “Start” → “Devices and Printers”. Right click “HPRT MT800” and choose “Printer properties”.
MT800 User Manual 2. Choose “General”, click “Print Test Page”, then it will print the current settings.
MT800 User Manual 3. Click “Advanced” to set the available time for printing.
MT800 User Manual 7.6 Uninstall Windows Driver 1. Double click Windows Driver. 2. Choose “English” and click “OK”. 3. Choose “Uninstall printer driver”. Click “Next”.
MT800 User Manual 4. Choose “HPRT MT800”, click “Next”. Then it is complete to uninstall. 4. Click “Yes” to uninstall the driver.
MT800 User Manual 8. Mac Driver 8.1 Mac Driver Installation Warning: Under different operating systems, the screen has slight difference. Please operate it according to the tips. Take MacOS 10.15 as example. 1. Double click the Mac Driver of MT800. 2. Click “Continue”.
MT800 User Manual 3. Click “Continue”. 4. Click “Continue”.
MT800 User Manual 5. Click “Install”. 5. Type in the password and click “Install Software”.
MT800 User Manual 6. The installation was successful.
MT800 User Manual 8.2 How to Print From Mac 1. Click “System Preferences”. 2. Choose “Printers & Scanners”.
MT800 User Manual 3. Click “+” to add the printer. 4. Choose MT800 device and click “Select Software”.
MT800 User Manual 5. Choose MT800 software and click “OK”. 6. Click “Add”.
MT800 User Manual 7. MT800 printer has been added. 8. Open the file to print, click “File” and select “Print”.
MT800 User Manual 9. Set up as needed, then click “Print”.
MT800 User Manual 9. Mobile Utility Tool 9.1 Operating System(OS) Environment Utility Tool is applicable to the following operating system: Microsoft Windows 10 (32 bit/64 bit) Microsoft Windows 8 (32 bit/64 bit) Microsoft Windows 7 SPI (32 bit/64 bit) Microsoft Windows Vista SP2 (32 bit/64 bit) Microsoft Windows XP Professional SP3 (32 bit) Microsoft Windows Server 2012(64 bit) 9.2 Utility Tool Preparation The installation file name is HPRTUtilityForMobile_Dealer VX.X.X.
MT800 User Manual 9.3 Using Utility Tool Warning: Under different operating system, the screen has slight difference. Please operate it according to the tips. Take Windows 7 as example. 1. Unzip the compressed package file, then open the folder, click Utility For Mobile.
MT800 User Manual 9.3.1 Add Printer 1. Click “Add Printer”. 2. Choose the right printer model and port type, then click “OK”. 3. Add printer is finished.
MT800 User Manual 9.3.2 Modify Printer 1. Choose the printer that needs to be modified. Click on "Modify Printer". 2. Choose the printer model and port type that needs to be modified, then click “OK”. 3. Modify the new printer is finished.
MT800 User Manual 4. For example, when connecting via Bluetooth, you need to change the port to COM to connect. Please do as follows: 1) Turn on the printer. 2) Turn on the computer. The Bluetooth icon will show at the lower right of the screen. If the computer is not configured with Bluetooth function, you need to insert a Bluetooth Dongle into its USB connector. 3) Right click the icon, choose "Add a Device".
MT800 User Manual 4) Find the corresponding printer, click “Next”. 5) Add a printer successfully as shown in the figure. The printer takes MT800-140C for an example.
MT800 User Manual 6) Click “Start" → “Devices and Printers”. Right click “MT800-140C” and choose “Properties”. 7) In “MT800-140C Properties”, choose“Services” the figure, the port of MT800-140C is COM3. 57 and find the corresponding port.
MT800 User Manual 8) Open the printer utility and click “Modify Printer”. 9) Choose “Printer Model” as MT800, “Port Type” as COM, “COM Port” as COM3. Then click “OK”.
MT800 User Manual 10) Modify printer successfully.
MT800 User Manual 9.3.3 Delete Printer 1. Choose the printer which you want to delete in the list, then click "Delete Printer". 2. Click “OK ”, then the printer is deleted.
MT800 User Manual 9.3.4 Connection Test 1. Click “Connection Test”. If the connection is successful, it will appear the following window. Note: 1. Make sure the printer is connected with computer and power on. 2. Before using the following functions, carry out the “Connection Test” first.
MT800 User Manual 9.3.5 Functions The function of Printer Utility For Mobile contains four items. Click the button and printer will execute the appropriate action. Note: The following screen may differ depending on the device to which you connect. Please operate it according to the actual interfaces. 1. Print Self Information: the printer will print out setting information.
MT800 User Manual 2. Parameter Config: to set “Bluetooth”, “Print Density”, “Power Down Time” in the Parameter setting. When completing the above settings, please restart the printer. Note: Power Down Time is only valid for unconnected Bluetooth.
MT800 User Manual 9.4 Firmware Update 1. Click “Firmware Update”. 2. Select the appropriate upgrade file and click “Download”.
MT800 User Manual 3. The firmware upgrade was successful and please restart the printer.
MT800 User Manual 10. Software Download 1) Log in the HPRT website http://www.hprt.com/Downloads.html 2) Choose product model “MT800”. 3) Choose “Drivers” or “Utility” as needed.
MT800 User Manual 4) Click “Download”.
MT800 User Manual FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
