Spare part
number
Description
506677-081 Keyboard with pointing stick for use in Denmark
506677-091 Keyboard with pointing stick for use in Norway
506677-111 Keyboard with pointing stick for use in Switzerland
506677-121 Keyboard with pointing stick for use in French Canada
506677-131 Keyboard with pointing stick for use in Portugal
506677-141 Keyboard with pointing stick for use in Turkey
506677-151 Keyboard with pointing stick for use in Greece
506677-161 Keyboard with pointing stick for use in Latin America
506677-171 Keyboard with pointing stick for use in Saudi Arabia
506677-201 Keyboard with pointing stick for use in Brazil
506677-211 Keyboard with pointing stick for use in Hungary
506677-221 Keyboard with pointing stick for use in the Czech Republic
506677-231 Keyboard with pointing stick for use in Slovakia
506677-251 Keyboard with pointing stick for use in Russia
506677-281 Keyboard with pointing stick for use in Thailand
506677-291 Keyboard with pointing stick for use in Japan
506677-A41 Keyboard with pointing stick for use in the Netherlands and Europe
506677-AB1 Keyboard with pointing stick for use in Taiwan
506677-AD1 Keyboard with pointing stick for use in South Korea
506677-B71 Keyboard with pointing stick for use in Finland and Sweden
506677-BB1 Keyboard with pointing stick for use in Israel
506677-DD1 Keyboard with pointing stick for use in Iceland
506678-001 Intel WiFi Link 5100ABGN with AMT (802.11a/b/g/n WLAN module) for use in the United States and Canada
506680-001 Intel WiFi Link 5100ABG with AMT (802.11a/b/g WLAN module) for use in the United States and Canada
513946-001 System board with ULV SU9400 processor (includes processor, replacement thermal material, and
replacement thermal material cleaning kit)
513947-001 System board with LV SL9600 processor (includes processor, replacement thermal material, and replacement
thermal material cleaning kit)
513948-001 250-GB, 5400-rpm, 6.35-cm (2.50-inch) secondary hard drive
513949-001 320-GB, 7200-rpm, 6.35-cm (2.50-inch) secondary hard drive
513950-001 160-GB, 5400-rpm, 6.35-cm (2.50-inch) secondary hard drive
514059-001 Top cover (includes TouchPad board and cable, TouchPad button board and cable, and TouchPad bracket)
36 Chapter 3 Illustrated parts catalog
