Spare part
number
Description
492570-001 1-GB, PC2-6400, 800-MHz, DDR2 memory module
492571-001 2-GB, PC2-6400, 800-MHz, DDR2 memory module
492572-001 4-GB, PC2-6400, 800-MHz, DDR2 memory module
492573-001 Microphone
492574-001 6.35-cm (2.50-inch) secondary hard drive cage assembly (includes additional USB port)
492575-001 12.1-inch, WXGA AntiGlare display assembly (without webcam)
492576-001 12.1-inch, WXGA AntiGlare display assembly (with webcam)
492577-001 Plastics Kit
492578-001 Rubber Kit (includes all rubber/mylar computer components)
492579-001 Screw Kit
492581-001 Smart card reader
492582–001 Heat sink (includes replacement thermal material and replacement thermal material cleaning kit)
495019-001 Display bezel for use with models that do not include a webcam (include HP logo and computer model number
label)
495020-001 Display enclosure without webcam (includes HP logo, wireless antenna transceivers and cables)
495021-001 Display panel cable for use with models that do not include a webcam
495022-001 Display bezel for use with models that do not include a webcam (include HP logo and computer model number
label)
495023-001 Display panel cable for use with models that include a webcam
495026-001 4.57-cm (1.80-inch) primary hard drive connector board
495027-001 6.35-cm (2.50-inch) secondary hard drive connector board
495028-001 6.35-cm (2.50-inch) secondary hard drive system connector board
496490-001 Display enclosure with webcam (includes HP logo, wireless antenna transceivers and cables)
497013-001 Display bezel adhesive
498455-001 Optical drive bay insert assembly, includes additional USB port
499209-001 LED board (includes cable and Mylar cover)
503732-001 160-GB, 5400-rpm, 4.57-cm (1.80-inch ) primary hard drive
506677-001 Keyboard with pointing stick for use in the United States
506677-021 Keyboard with pointing stick for use in Europe
506677-031 Keyboard with pointing stick for use in the United Kingdom
506677-041 Keyboard with pointing stick for use in Germany
506677-051 Keyboard with pointing stick for use in France
506677-061 Keyboard with pointing stick for use in Italy
506677-071 Keyboard with pointing stick for use in Spain
Sequential part number listing 35
