12.1-inch, WXGA display specifications
Metric U.S.
Dimensions
Height
16.9 cm 6.7 in
Width 26.2 cm 10.3 in
Diagonal 30.8 cm 12.1 in
Number of colors Up to 16.8 million
Contrast ratio 250:1 (typical)
Brightness 180 nits (typical)
Pixel resolution
Pitch
0.279 × 0.279 mm
Format 1280 × 800
Configuration RGB vertical stripe
Backlight Edge lit
Character display 80 × 25
Total power consumption 4.0 W
Viewing angle +/-40 horizontal, +20/–40° vertical (typical)
