Laptop User Manual
Table Of Contents
- Product description
- External component identification
- Illustrated parts catalog
- Removal and replacement procedures
- Preliminary replacement requirements
- Component replacement procedures
- Service tag
- Computer feet
- Battery
- SIM
- Bluetooth module
- Expansion memory module
- WLAN module
- Primary hard drive
- WWAN module
- Optical drive
- Switch cover and keyboard
- LED board
- RTC battery
- Secondary hard drive
- Primary memory module
- Display assembly
- Top cover
- Speaker
- System board
- ExpressCard assembly
- Modem module
- Fan
- Heat sink
- Computer Setup
- Specifications
- Computer specifications
- 12.1-inch, WXGA display specifications
- Hard drive specifications
- DVD-ROM Drive specifications
- DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive specifications
- System DMA specifications
- System interrupt specifications
- System I/O address specifications
- System memory map specifications
- Screw listing
- Backup and recovery
- Connector pin assignments
- Power cord set requirements
- Recycling
- Index
Category Description
S4/S5 wake on LAN on AC power
NIC power-down technology
Wireless LAN Integrated WLAN options by way of mini-slot which supports WLAN only:
Support for 2 dual-band 2.4-/5.0-GHz WLAN antennae cabled to mini-slot
Support for the following WLAN options:
●
802.11a/b/g with Intel Active Management Technology (iAMT) support
●
802.11a/b/g/n with iAMT support
●
802.11a/b/g/draft-n
●
802.11b/g
●
no-WLAN option
Integrated WWAN options by way of mini-slot which supports WWAN only:
Support for 2 five-band WWAN antennae cabled to mini-slot
SIM is user-accessible behind battery
Supports the following WWAN options:
●
HP un2400 Mobile Broadband Module
●
WWAN aftermarket option
Integrated WPAN option by way of mini-slot which supports WPAN only:
Supports no-wireless PAN option
Blueflame Bluetooth® module
External media card SD Card Reader supporting Secure Digital (SD) Memory Card and MultiMediaCard (MMC)
Ports Audio-in (stereo microphone)
Audio-out (stereo headphone)
Docking
RJ-11 (modem)
RJ-45 (Ethernet, includes link and activity lights)
USB (2 ports on models with an optical drive installed, 3 ports on models without an optical drive
installed)
VGA (Dsub 15-pin) supporting 1600 × 1200 external resolution at 75-GHz (hot plug/unplug with
auto-detect)
3-pin AC power via the HP Smart AC Adapter
Docking HP 2400/2500 Series Docking Station
Keyboard/pointing
devices
Full–size 4.5-mm×19.05-mm keyboard with embedded numeric keypad
Pointing stick with 2 pointing stick buttons
TouchPad with 2 TouchPad buttons and vertical scrolling zone
