System Configuration menu
NOTE: Some of the listed System Configuration options may not be supported by your computer.
Select To do this
Language Change the Computer Setup language.
Boot Options
●
Set a Startup Menu delay (in seconds).
●
Enable/disable Custom Logo (disabled by default).
●
Enable/disable Display Diagnostic URL (enabled by
default).
●
Enable/disable CD-ROM boot (enabled by default).
●
Enable/disable SD Card boot (enabled by default).
●
Enable/disable floppy boot (enabled by default).
●
Enable/disable PXE Internal NIC boot (enabled by
default).
●
Set the Express Boot Popup delay in seconds.
●
Set the boot order.
Device Configurations
●
Enable/disable USB legacy support (enabled by default).
When enabled, USB legacy support allows the
following:
◦
Use of a USB keyboard in Computer Setup even
when a Windows® operating system is not running.
◦
Startup from bootable USB devices, including a hard
drive, diskette drive, or optical drive connected by a
USB port to the computer.
●
Select a parallel port mode: ECP (Enhanced Capabilities
Port), standard, bidirectional, or EPP (Enhanced Parallel
Port).
●
Enable/disable fan always on while connected to an AC
outlet (enabled by default).
●
Enable/disable LAN Power Save (select models only).
When enabled, saves power by turning off the LAN when
not in use (enabled by default).
●
Enable/disable Data Execution Prevention. When
enabled, the processor can disable some virus code
execution, which helps to improve computer security.
●
SATA (Serial Advanced Technology Attachment) device
mode. The following options are available:
◦
AHCI (Advanced Host Controller Interface)
◦
IDE (Integrated Drive Electronics)
◦
RAID (select models only)
100 Chapter 5 Computer Setup
