User’s Guide 6–1
6
Preparing the Monitor for Shipping
Keep the original packing box in a storage area. You may need it later if you move or ship your monitor.
Removing the Cantilever Base
1. Disconnect the power, video, and audio cables from the monitor.
2. Set the monitor screen down on a flat, soft, protected surface.
3. Press the center tab in (1) and detach the base from the monitor (2).
Removing the cantilever base
WARNING: Before folding the monitor, turn off the monitor power, and disconnect all power, video, and audio
cables. To disconnect power from the equipment, unplug the power cord from the power outlet by grasping the
power plug firmly. Never pull on the cord.
CAUTION: The screen is fragile. Placing the monitor screen down on a flat, soft area prevents scratches, defacing,
or breakage. Avoid applying pressure to the LCD screen; doing so can cause damage.
