9 Use Cases
9.1 Object Diagrams
The following represents a possible instantiation of the HP Memory Profile. In this case, “system1” has
two memory modules.
For simplicity the properties have been removed from the classes.
memory1
: HP_Memory
HP_RealizesMemoryModule
mm1 :
HP_MemoryModule
system1 :
HP_ComputerSystem
mm2 :
HP_MemoryModule
HP_RealizesMemoryModule
HP_SystemMemory
Figure 3 – HP Memory Profile: Object diagram with two memory modules
