P00110_-_HP_Memory_Profile

10 Version 1.0.0
CIM_SystemDevice
(see DMTF Base Server profile)
HP_SystemMemory
Figure 2 – Memory Profile: Hierarchy Diagram
Figure 1 represents the class diagram for the HP Memory Profile.
The HP_Memory class describes logical aspects of system memory. The physical aspects of system
memory is optionally described using the HP_MemoryModule class, defined in the HP Memory Physical
Asset Profile.
The relationship between the computer system (HP_ComputerSystem) and logical memory is described
using the HP_SystemMemory association class.
Figure 2 represents the association hierarchy of for the HP Memory Profile.
7 Implementation Requirements
7.1 HP_Memory
There shall be one single instance of HP_Memory per the profile instantiation. This instance shall
represent the logical memory in the managed system.
7.1.1 HP_Memory.DeviceID
This property shall be set to the following value: “HPQ:<provider name>:000” where <provider name> is
the name of the provider that implements this class.
7.1.2 HP_Memory.ElementName
This property shall be set to the following value: “HP System Memory”
7.2 HP_SystemMemory
There shall be one single instance of HP_SystemMemory per the profile instantiation.
HP_SystemMemory represents the association between the HP_ComputerSystem instance and the
HP_Memory instance.
