HP Insight Management WBEM Providers SNMP Data Migration for vSphere 5.1 U2 September 2013
Table Of Contents
- 1 Introduction
- 2 Overview of the Insight Management MIB
- 3 High Level Mapping
- 4 Server MIB Variable to WBEM Property Mappings
- 5 Storage MIB Variable to WBEM Property Mappings
- 6 Network MIB Variable to WBEM Property Mappings
- 7 Server Trap to Indication Mappings
- 8 Storage Trap to Indication Mappings
- 9 Network Trap to Indication Mappings
- 10 Revisions
MIB OID Name
cpqSasLogDrvRaidLevel
WBEM Class and Property
SMX_SASStorageVolume.FaultTolerance
Notes
MIB OID
1.3.6.1.4.1.232.5.5.3.1.1.4
MIB OID Name
cpqSasLogDrvStatus
WBEM Class and Property
SMX_SASStorageVolume.OperationalStatus
SMX_SASStorageVolume.ExtentStatus
Notes
MIB OID
1.3.6.1.4.1.232.5.5.3.1.1.5
MIB OID Name
cpqSasLogDrvCondition
WBEM Class and Property
SMX_SASStorageVolume.OperationalStatus
SMX_SASStorageVolume.ExtentStatus
Notes
MIB OID
1.3.6.1.4.1.232.5.5.3.1.1.6
MIB OID Name
cpqSasLogDrvRebuildingDisk
WBEM Class and Property
SMX_SASStorageExtent.ExtentStatus
Notes
Via association traversal
MIB OID
1.3.6.1.4.1.232.5.5.3.1.1.7
MIB OID Name
cpqSasLogDrvCapacity
WBEM Class and Property
SMX_SASStorageVolume.BlockSize * NumberOfBlocks
Notes
MIB OID
1.3.6.1.4.1.232.5.5.3.1.1.8
MIB OID Name
cpqSasLogDrvStripeSize
WBEM Class and Property
Not Implemented
Notes
MIB OID
1.3.6.1.4.1.232.5.5.3.1.1.9
MIB OID Name
cpqSasLogDrvPhyDrvIds
