Installing and Configuring HSG Agent
4–2 HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
To receive information about the devices connected to your HSG80 controller over a
TCP/IP network, you must install the Agent on a computer that is connected to a
controller.
The Agent can also be used as a standalone application without Client. In this mode,
which is referred to as Agent only, Agent monitors the status of the subsystem and
provides local and remote notification in the event of a failure. A subsystem includes
the HSG80 controller and its devices. Remote and local notification can be made by
email and/or SNMP messages to an SNMP monitoring program.
NOTE: For serial and SCSI connections, the Agent is not required for creating virtual disks.
Installation and Configuration Overview
Table 4–2 provides an overview of the installation.
Table 4–1: SWCC Features and Components
Features
Agent
Required?
Client
Required?
Creation of RAID sets:
■ Striped device group (RAID 0)
■ Mirrored device group (RAID 1)
■ Striped mirrored device group (RAID 0+1)
■ Striped parity device group (RAID 3/5)
■ Individual device (JBOD)
Ye s Ye s
Monitor multiple subsystems at once Ye s No
Event logging Ye s No
Email notification Ye s No
Pager notification Ye s Ye s
Table 4–2: Installation and Configuration Overview
Step Procedure
1 Verify that your hardware has been set up correctly. See the previous
chapters in this guide.
2 Verify that you have a network connection for the Client and Agent
systems.
