Data Replication manager with Compaq Tru64 UNIX Logical Storage Manager

Administering LSM
Application Notes – Data Replication Manager with HP Tru64 UNIX Logical Storage Manager 11
5. You will see a display similar to the one shown in Figure 5.
Figure 5: Unmount File System confirmation window
6. Click OK to unmount the volume.
Deporting a Disk Group
To deport a disk group:
1. Right-click the disk group.
2. Select Deport, as shown in Figure 6.
Figure 6: Deport Disk Groups window
3. When the disk group is deported, you can disable host access from the controllers and continue
with the failover or failback operation. You will see a display similar to the one shown in Figure 7.
Figure 7: Deport Disk Group confirmation window
4. Click OK to deport the disk group.
