Service manual
Table Of Contents
- 1 Specifications
- 2 Controls, Ports, and Indicators
- 3 Connector Pinouts
- 4 Maintenance Guidelines
- 5 Error Messages
- 6 Diagnostics
- 7 Maintenance and Troubleshooting
- Preventive Maintenance Procedures
- Troubleshooting
- Password Problems
- General Server Problems
- No lights are on and no error message appears
- Operating system or an application is not responding properly
- Server stops working (hangs)
- Server does not start (boot)
- Power Problems
- Video/Monitor Problems
- Configuration Problems
- Printer/Datacomm Problems
- Keyboard and Mouse Problems
- Flexible Disk Drive Problems
- CD-ROM Problems
- SCSI Problems
- Processor Problems
- Memory Problems
- Embedded Network Interface Card Problems
- Network Interface Card (Installed) Problems
- 8 Parts and Illustrations
- 9 Remove/Replace Procedures
- Introduction
- Covers
- Front Bezels
- Status Panel Assembly
- Mass Storage Devices
- Removing the Flexible Disk Drive
- Replacing the Flexible Disk Drive
- Removing the CD-ROM
- Replacing the CD-ROM
- Removing a Backup Tape Drive
- Replacing a Backup Tape Drive
- Removing a Hard Disk Drive (Tray Mounted)
- Replacing a Hard Disk Drive (Tray Mounted)
- Removing a Hard Disk Drive (Drive Cage Mounted)
- Replacing a Hard Disk Drive (Drive Cage Mounted)
- DIMMs
- Processor
- Accessory Boards
- Power Supply
- Battery
- Chassis Fan
- System Board
- Index
7
1 Specifications
Technical Specifications
The specifications listed below for HP Tower Server tc2100 may vary if you install a mass storage device in
your server that has more stringent environmental limits. Ensure the operating environment for your server is
suitable for all of the mass storage devices being used.
Environmental
Temperature
Operating
5° to 35° C (41° to 95° F)
Non-operating
-40° to +65° C (-40° to +149° F)
Humidity
Operating
20% to 80% relative humidity, non-condensing
Non-operating
5% to 95% relative humidity, non-condensing
Altitude
Operating
-30 to 3,000 m (~ 10,000 ft)
Non-operating
-30 to 12,000 m (~ 40,000 ft)
Thermal Output
Maximum Operating
1066 BTU/hr
Weight and Dimensions
Weight
Basic configuration approx. 13.5 kg. (30 lbs) – excludes keyboard and monitor.
Fully loaded approx. 22.6 kg. (50 lbs) – excludes keyboard and monitor.
Height
46.0 cm (18.11 inches)
Width
20.5 cm (8.07 inches)
Depth
46.7 cm (18.39 inches)
Power Supply Specifications
Parameter Characteristics
Input Type Manual voltage selection
Input – Maximum Range 100 to 127 VAC @ 50/60 Hz
200 to 240 VAC @ 50/60 Hz
Operating Current 100 to 127 VAC: 7.0 A
200 to 240 VAC: 3.5 A
In-rush Current 90 A (cold) 120 A (warm)
Operating Power 250 W Continuous
