Chapter 4 Maintenance Guidelines
26
• 1 external 68-pin connector – This external SCSI connector is only used for external SCSI devices and
requires no additional internal cabling or switch settings. This connector supports up to 15 devices
connected to it externally.
NOTE Only one 68-pin connector on the SCSI controller board can be used as the active SCSI
connector. Therefore, you can not connect external SCSI devices to the external connector
when there are active internal SCSI devices connected to the internal SCSI connector.
The HP Server tc2100 will support an HP NetRAID 1M controller board, separate from the SCSI controller
board.
