Beacon mode
The HP StoreOnce Backup System supports a Beacon LED sequence, which helps a user identify
which unit is being configured, if several are connected to the network. AL HP D2D4000 Series
Backup System also have a Beacon LED on the individual disks so that you can identify a specific
disk within the HP D2D.
Use the Network page of the Web Management Interface to turn Beacon Mode on and off for the
HP StoreOnce Backup System. This turns the Beacon LED on the front and the rear of the HP D2D
solid blue. If you do not switch off Beacon Mode, it will continue for 5 minutes. See also Network
(Configuration) (page 33). You can also switch Beacon mode on and off by pressing the LED on
the front panel.
Fibre Channel card LEDs
If you have the Fibre Channel version of the HP D2D, there are three LEDs adjacent to each FC
port.
Table 26 FC card LEDs
ActivityAmber LEDGreen LEDYellow LED
Power Off (OK)OffOffOff
Power on before or after software initialization.
Awaiting HBA software initialization.
OnOnOn
Power on after software initialization. Link not
initialized.
FlashingFlashingFlashing
software fault (OK)Alternately flashingAlternately flashingAlternately flashing
Connected at 2 (HP D2D4300 Series only) or
1 (all other FC systems) Gb/s
OnOffOff
Activity at 2 (HP D2D4300 Series only) or 1
(all other FC systems) Gb/s (OK)
FlashingOffOff
Connected at 4 (HP D2D4300 Series only) or
2 (all other FC systems Gb/s
OffOnOff
Activity at 4 (HP D2D4300 Series only) or 2
(all other FC systems)Gb/s (OK)
OffFlashingOff
Connected at 8 (HP D2D4300 Series only) or
4 (all other FC systems) Gb/s
OffOffOn
Activity at 8 (HP D2D4300 Series only) or 4
(all other FC systems) Gb/s (OK)
OffOffFlashing
Capacity upgrade kit LEDs
There are three LEDs on the front of the Capacity Upgrade Kit.
Fibre Channel card LEDs 119
