Using the Storage Window
82 Command Console V2.5 User Guide
The configuration settings, such as caches, LUNs, host port, and stripe size,
are restored.
Caution: If the original hardware and connections are replaced or are not
saved before making new changes, you cannot restore the original
configuration settings.
