Fan module spec
ifications
Parameter
Value
Height
6.0 cm (2.36 in)
Width
6.0 cm (2.36 in)
Depth
26.8 cm (10.6 in)
Weight 0.50 kg (1.10 lbs)
SCSI I/O module specifications
Parameter
Value
Height
8.13 cm (3.2 in)
Width
2.34 cm (0.92 in)
Depth
37.14 cm (14.62 in)
Weight 0.46 kg (1.01 lbs)
Power sup
ply module specifications
Paramete
r
Value
Height
7.7cm(3.0in)
Width
6.4cm(2.5in)
Depth
32.0 cm (12.6 in)
Weight 1.80 kg (3.96 lb)
