1 Illustrated parts list
This section provides an illustrated parts breakdown and spare parts list for the HP StorageWorks 1510i
Modular Smart Array (MSA1510i).
Item
Description
Service replacement
module part number
Additional/optional
module part number
Custom
er Self Repair
Standard shipping configuration items:
1
Power supply modules
349800–001 /
406442–001
n/a
Mandatory
2
SCSI I
/O module
70–41213–S1 /
70–41213–T1
AA988A
Optional
3
Fan modules
349798–001
n/a
Mandatory
4
2–Port Ethernet iSCSI
module
417788 –0 01 A D53 8– 040 01
Optional
5
Chassis with
backplane
70–41
211 –S1 /
70/4
1211 – T1
n/a
Optional
6
MSA Chassis bezel
70–41220–S1
n/a
Mandatory
