17Director Element Manager User Guide
1
Overview
This chapter provides an introduction to the HP StorageWorks Director 2/64 and
Director 2/140 Element Managers. It is intended as a quick reference for using
features available through the main Element Manager window of the High
Availability Fabric manager (HAFM) application.
■ Feature Keys, page 18
■ Managing the Director, page 19
■ Element Manager Description, page 20
■ Using the Element Manager, page 24
■ Backing Up and Restoring Element Manager Data, page 58
