RIP Preview
The preview has to be recalculated as soon as sizes are changed in the tab GENERAL or if you use a
new original.
Select an Area
An arbitrary area can be defined from the preview: this is the “AOI” or area of interest. To set an area of interest,
draw a rectangle around the desired section, keeping the left mouse button pressed. The size of the defined area
is entered as the COPY SIZE in the tab GENERAL.
The AOI can be enlarged or reduced in any direction. To do this, move the mouse pointer to an edge of the
rectangle so that a double-arrow appears. Move then this arrow in the height or width.
To move the AOI to a new position, click into the AOI and move it while keeping the left mouse button pressed.
Edit AOI
Instead of dragging the AOI
manually, you can exactly determine
its width, height and position and
enter a scaling factor.
To open the window E
DIT AOI,
right-click into the picture or in the
AOI and select E
DIT AOI.
Reset AOI Setting
This option cancels the current AOI. The complete image is displayed again and will be printed in full
size.
Apply Filtering
This option shows the effects caused by the current filtering and color management.
Further details according to Filters and Color Management are explained in §
USE COLOR MANAGEMENT, §
FILTERS and § FILTER EDITOR.
