Specifications 87
Specifications
Environmental specifications
Specification Value
Temperature range*
Operating
10°C to 35°C (50°F to 95°F)
Shipping
-40°C to 70°C (-40°F to 158°F)
Maximum wet bulb temperature
28°C (82.4°F)
Relative humidity
(noncondensing)**
Operating
10% to 90%
Nonoperating
5% to 95%
* All temperature ratings shown are for sea level. An altitude derating of 1°C per 300 m (1.8°F per 1,000 ft) to 3,048
m (10,000 ft) is applicable. No direct sunlight allowed.
** Storage maximum humidity of 95% is based on a maximum temperature of 45°C (113°F). Altitude maximum for
storage corresponds to a pressure minimum of 70 kPa.
Mechanical specifications
• 1U-node specifications
Dimensions Value
Height
4.15 cm (1.63 in)
Depth
53.55 cm (21.08 in)
Width
17.56 cm (6.91 in)
Weight (maximum)
3.62 kg (7.97 lb)
• 2U-node specifications
Dimensions Value
Height
8.37 cm (3.29 in)
Depth
53.55 cm (21.08 in)
Width
17.56 cm (6.91 in)
Weight (maximum)
5.27 kg (11. 62 lb)
