User guide

Specifications 86
Specifications
Environmental specifications
Specification Value
Temperature range*
—
Operating
10°C to 35°C (50°F to 95°F)
Non-operating
-30°C to 60°C (-22°F to 140°F)
Relative humidity
(noncondensing)**
—
Operating
10% to 90% @ 28°C (82.4°F)
Non-operating
5% to 95% @ 38.7°C (101.7°F)
Altitude†
—
Operating
3050 m (10,000 ft)
Non-operating
9144 m (30,000 ft)
* The following temperature conditions and limitations apply:
- All temperature ratings shown are for sea level.
- An altitude derating of 1°C per 304.8 m (1.8°F per 1,000 ft) up to 3048 m (10,000 ft) applies.
- No direct sunlight is allowed.
-The maximum permissible rate of change is 10°C/hr (18°F/hr).
- The type and number of options installed may reduce the upper temperature and humidity limits.
- Operating with a fan fault or above 30°C (86°F) may reduce system performance.
** Storage maximum humidity of 95% is based on a maximum temperature of 45°C (113°F).
†Maximum storage altitude corresponds to a minimum pressure of 70 kPa (10.1 psia).
Server blade specifications
Specification Value
Height
18.16 cm (7.15 in)
Depth
50.95 cm (20.06 in)
Width
5.56 cm (2.19 in)
Weight (maximum)
6.44 kg (14.20 lb)
Weight (no drives installed)
4.87 kg (10.75 lb)
