Cabling 40
4.
Connect a USB keyboard to the second USB connector.
Item Description
1 Monitor
2 USB mouse
3 Local I/O cable
4 Server blade
5 Video connector
6 USB keyboard
Accessing local media devices
Use the following configuration when configuring a server blade or loading software updates and
patches from a USB CD/DVD-ROM or a USB diskette.
1. Connect the local I/O cable to the server blade.
2. Connect the video connector to a monitor.
3. Connect a USB hub to one USB connector.
4. Connect the following to the USB hub:
• USB CD/DVD-ROM drive
• USB keyboard
• USB mouse
• USB diskette drive
