Cabling 39
Cabling
In this section
Using the local I/O cable........................................................................................................................ 39
Connecting locally to a server blade with video and USB devices................................................................ 39
Using the local I/O cable
The local I/O cable enables the user to perform server blade administration, configuration, and
diagnostic procedures by connecting video and USB devices directly to the server blade. For local I/O
cable connectors, see "Local I/O cable (on page 13)."
Connecting locally to a server blade with video and USB
devices
Use the local I/O cable to connect a monitor and any of the following USB devices:
• USB hub
• USB keyboard
• USB mouse
• USB CD/DVD-ROM drive
• USB diskette drive
Numerous configurations are possible. This section offers two possible configurations. For more
information, see "USB support and functionality (on page 54)."
Accessing a server blade with local KVM
CAUTION: Before disconnecting the local I/O cable from the connector, always squeeze the release
buttons on the sides of the connector. Failure to do so can result in damage to the equipment.
NOTE: For this configuration, a USB hub is not necessary. To connect additional devices, use a USB hub.
1. Connect the local I/O cable to the server blade.
2. Connect the video connector to a monitor.
3. Connect a USB mouse to one USB connector.
