Spare part
number
Description
538313-001 16.0-inch WXGA BrightView LED display assembly for use in black computers
538314-001 15.6-inch WXGA AntiGlare LED display assembly for use in black computers
538315-001 16.0-inch WXGA AntiGlare LED display assembly for use in black computers
538348-001 15.6-inch WXGA BrightView LED display assembly for use in white computers
538349-001 16.0-inch WXGA BrightView LED display assembly for use in white computers
538350-001 15.6-inch WXGA AntiGlare LED display assembly for use in white computers
538351-001 16.0-inch WXGA AntiGlare LED display assembly for use in white computers
538354-001 15.6-inch WXGA AntiGlare LED display assembly for use in MTV2 artist edition computers
538355-001 16.0-inch WXGA AntiGlare LED display assembly for use in MTV2 artist edition computers
570094-001 BrightView display panel for use only with computers equipped with 16-inch LED display panels (includes
display panel cable)
570095-001 BrightView display panel for use only with computers equipped with 15.6-inch LED display panels
(includes display panel cable)
570205-001 Switch cover for use in MTV2 artist edition computers (includes LED board and cable)
570206-001 Top cover for use only with MTV2 artist edition computers
570228-001 Black textured keyboard for use in the United States
570228-031 Black textured keyboard for use in the United Kingdom
570228-041 Black textured keyboard for use in Germany
570228-051 Black textured keyboard for use in France
570228-061 Black textured keyboard for use in Italy
570228-071 Black textured keyboard for use in Spain
570228-111 Black textured keyboard for use in Switzerland
570228-121 Black textured keyboard for use in French Canada
570228-131 Black textured keyboard for use in Portugal
570228-141 Black textured keyboard for use in Turkey
570228-161 Black textured keyboard for use in Latin America
570228-171 Black textured keyboard for use in Saudi Arabia
570228-201 Black textured keyboard for use in Brazil
570228-211 Black textured keyboard for use in Hungary
570228-221 Black textured keyboard for use in the Czech Republic
570228-251 Black textured keyboard for use in Russia
570228-281 Black textured keyboard for use in Thailand
570228-291 Black textured keyboard for use in Japan
570228-B31 Black textured keyboard for use internationally
Sequential part number listing 39
