Bottom components
Component Description
(1)
Battery bay
Holds the primary battery pack.*
(2)
Battery pack release latch
Releases the battery pack from the battery bay.
(3)
Memory module compartment Contains the memory module slots.
(4)
Hard drive bay
Holds the hard drive.
(5)
Vents (2)†
Enable airflow to cool internal components.
CAUTION To prevent overheating, do not obstruct vents. Use the
computer only on a hard, flat surface. Do not allow another hard
surface, such as an adjoining optional printer, or a soft surface,
such as pillows or thick rugs or clothing, to block airflow.
NOTE The computer fan starts up automatically to cool internal
components and prevent overheating. It is normal for the internal
fan to cycle on and off during routine operation.
*Battery packs vary by model.
†The computer has 3 vents. One other vent is located on the rear of the computer.
ENWW Components 11
