Chapter 2 41
Database Structure and Protection
Data Set Types and Relationships
Manual versus Automatic Data Sets
Database designers can choose a manual or automatic master data set depending on the
following:
• Manual masters help ensure that valid search item values are entered for related detail
entries. They can also serve as indexes to detail data sets.
• Automatic masters serve as indexes to detail data sets and save time when the search
item values are unpredictable or so numerous that manual addition and deletion of
master entries is undesirable.
Whenever a single data item is sufficient for a master data set, the database designer must
decide between the control of data entry available through manual masters and the
program simplicity offered by automatic masters. For example, because DATE-MASTER is
an automatic data set, erroneous dates such as 331299 can be accidentally entered.
Detail Data Sets
Detail data sets have the following characteristics:
• They are used to record information about related events such as information about all
sales to the same account.
• They allow retrieval of all entries pertaining to a uniquely identifiable entity. For
example, account number 95430301 can be used to retrieve information about all sales
made to Ms. Brighton.
• They can be defined with from zero to 16 search items (unlike a master data set which
contains at most one key item). The values of a particular search item need not be
unique. Generally, a number of entries will contain the same value for a specific search
item.
• They can be defined for automatic expansion of their capacity.
The SALES data set contains four search items: ACCOUNT, STOCK#, PURCH-DATE,
and DELIV-DATE. Two entries in the example in Figure 2-3. have identical values for the
ACCOUNT item in the SALES data set. TurboIMAGE/XL stores pointer information with
each detail data entry that links all entries with the same search item value. Entries
linked in this way form a chain. A search item is defined for a detail data set to retrieve all
entries with a common search item value (that is, all entries in a chain). The SALES
entries with ACCOUNT equal to 95430301 form a two-entry chain. The number of entries
in a single chain is limited only by the maximum number of entries in a data set.
Paths
A master data set key item can be related to a detail data set search item of the same type
and size. This relationship forms a path. A path contains a chain for each unique search
item value. In Figure 2-3., the ACCOUNT key item in CUSTOMER and the ACCOUNT
search item in SALES form a path to link the CUSTOMER master data set to the SALES
detail data set. One chain links all SALES entries for account number 95430301. The
chain for account number 12345678 consists of one entry. Both chains belong to the same
path.
