SNA Link/iX Node Managers Guide (30291-90009)

Chapter 3 91
Logging Configuration
Configuring Logging
NOTE If you want the logging events for only a specific logging subsystem and
class to be displayed at the list devices of users, see “Enabling Users for
a Specific Subsystem and Class” later in this chapter.
File
For display only. The name of the configuration file.
Once you have entered all of the logging information,
press
[f6] (Save Data).
Then, if you do not want to configure logging
information for other SNA subsystems, press [f5]
(Validate HP-IBM) to validate the logging
configuration you just did. Once the logging
configuration is validated, press
[f4] (Exit Logging) to
return to the “HP-IBM Configuration” screen.
If you want to configure logging information for other
SNA subsystems, (1) press
[f8] (Prior Screen), which
places you at the “IBM Logging Configuration (1)”
screen (described earlier in this chapter); or (2) press
[f1] (Next Screen), which places you at the “IBM
Logging Configuration (3)” screen (described next in
this chapter).
IBM Logging Configuration (3) Screen
On this screen, you specify logging information for these subsystems:
SNADS and token ring link.
NOTE Although the logging subsystem for RJE/BSC Link (SUB0037) is shown
on the “IBM Logging Configuration (3)” screen, information for
configuring RJE/BSC Link logging is not included in this manual. See
the RJE/XL Node Manager’s Guide for that information.
If you want to specify logging information for an SNA subsystem not
shown on this screen, press
[f8] (Prior Screen) until you are placed at
either the “IBM Logging Configuration (2)” screen or the “IBM Logging
Configuration (1)” screen. Each of these screens is described earlier in
this chapter.
