SNA Link/iX Node Managers Guide (30291-90009)

Chapter 2 61
SNA Node and Link Configuration
Configuring the SNA Node and Link
4 X SlotNumber
where (a) X is the multiplication sign ( not the
character “X”), and (b)
SlotNumber is the number of
the slot the PSI is in.
Example:
If the PSI is in slot 6, the Physical Path is 24
(4 multiplied by 6).
• If two card cages are present:
PathNumber/ ( 4 X SlotNumber )
where (a)
PathNumber is a number corresponding to
the card cage the PSI is in:
Card cage 0: PathNumber = 2 Card cage 1:
PathNumber = 6
(b) / is the slash character (
not the division sign), (c)
the parentheses are used to set off the arithmetic
formula (they are
not entered as part of the
Physical Path value), (d) X is the multiplication
sign (
not the character “X”), and (e) SlotNumber is
the number of the slot, within the card cage, the PSI
is in.
Examples:
If the PSI is in card cage 0, slot number 4, the
Physical Path is
2/16
(
PathNumber , slash character, 4 multiplied by 4).
If the PSI is in card cage 1, slot number 3, the
Physical Path is
6/12
(
PathNumber , slash character, 4 multiplied by 3).
Receive Timeout
Required. The number of seconds the SDLC link
driver will wait for the remote system poll before
closing the line. If 0 is specified, no timeout occurs.
Range: 0, 30-1800 (integer)
Recommended value: 180 (30 in Europe)
Default: 180
