SNA Link/iX Node Managers Guide (30291-90009)

46 Chapter2
SNA Node and Link Configuration
NMMGR Configuration Overview
---- -- ---- -- ---- -- ---- --
LU01 1 LU02 2 LU03 3 LU04 4
LU05 5 LU06 6 LU07 7 LU08 8
LU09 9 LU10 10 LU11 11 LU12 12
LU13 13 LU14 14 LU15 15 LU16 16
X25LINK:
NS NI Name: X25NI Inactivity Timeout: 0
VC Type: PVC Call Direction: OUT
Max Call Retries: 3 Call Retry Delay: 600
PVC Number: 1 Remote Address:
-------------------------------------
SNANODE NAME: SVCIN16
ID Blk: 023 ID Num: FFFF4 Max Data: 265 Type: X.25
LU Name LU# LU Name LU# LU Name LU# LU Name LU#
---- -- ---- -- ---- -- ---- --
LU01 1 LU02 2 LU03 3 LU04 4
LU05 5 LU06 6 LU07 7 LU08 8
LU09 9 LU10 10 LU11 11 LU12 12
LU13 13 LU14 14 LU15 15 LU16 16
X25LINK:
NS NI Name: X25NI Inactivity Timeout: 0
VC Type: SVC Call Direction: IN
Max Call Retries: 3 Call Retry Delay: 600
PVC Number: Remote Address: 01
-------------------------------------
SNANODE NAME: SVCOUT
ID Blk: 023 ID Num: FFFF5 Max Data: 265 Type: X.25
LU Name LU# LU Name LU# LU Name LU# LU Name LU#
---- -- ---- -- ---- -- ---- --
LU01 1 LU02 2 LU03 3 LU04 4
LU05 5 LU06 6 LU07 7 LU08 8
LU09 9 LU10 10 LU11 11 LU12 12
LU13 13 LU14 14 LU15 15 LU16 16
X25LINK:
NS NI Name: X25NI Inactivity Timeout: 0
VC Type: SVC Call Direction: OUT
Max Call Retries: 3 Call Retry Delay: 600
PVC Number: Remote Address: 01
-------------------------------------
SNANODE NAME: TEMP
