SNA Node and Link Configuration
Data Required from the Host Configuration
Data Required from the Host Configuration
Data in an SNA node configuration file must correspond to information
from the host configuration. So, before using NMMGR, you should have
certain information from the host configuration.
The host information that corresponds to SNA node configuration
information for SNA/SDLC links, SNA/X.25 links, and SNA/Token Ring
links is described below.
SNA/SDLC Information
For the host and the HP 3000 to communicate, you must coordinate the
SNA/SDLC node configuration with the ACF/NCP and ACF/VTAM host
configurations. The HP SNA Products Remote System Configuration
Guide explains these configurations. Table 2-1 shows the relationships
between items from the host configuration and items in the SNA node
configuration file for an SNA/SDLC link. Each NMMGR screen field is
described later in this chapter.
Table 2-1 Host ACF/NCP and ACF/VTAM Values for SDLC
Host Configuration
Macro and Operand
Field in NMMGR Screen NMMGR Screen Name
LINE SPEED Transmission Speed SDLC Link Data
NRZI NRZI SDLC Link Data
PU puname SNA Node Name Configuration
New Name Configuration
ADDR Station ID SDLC Link Data
IDBLK ID BLK PU Data
IDNUM ID NUM PU Data
MAXDATA MAX DATA PU Data
PUTYPE Node Type PU Data
XID Node Type PU Data
LU luname LU Name LU Data
LOCADDR LU# LU Data
