MPE Commands
SNACONTROL STATUS
The current station address is the currently-active station address.
The default station address is the factory-configured default station
address.
The function address mask is the address mask as described in the IBM
Token-Ring Network Architecture Reference.
Transmits no error is the number of frames transmitted without errors.
Receives no error is the number of frames received without errors.
Transmit byte count is the number of bytes transmitted without errors.
Receive byte count is the number of bytes received without errors.
Transmit errors is the number of frames not successfully transmitted
because of errors.
Receive errors is the number of frames received with errors.
Session-Level Status Information
Regardless of the type of link being used, the same session-level status
information is displayed. An example of a session-level status display is
given below, and the terminology used is described after the example.
Example If either an SDLC, X.25, or token ring link is being used, typing
SNACONTROL STATUS;NODE=IBMNODE
where IBMNODE is already active could generate this display:
SESSION STATE STATUS FOR NODE : IBMNODE
NAME TYPE NAU STATE USER TRACE FILE
======== ======= ====== ========== =============== =========================
XPORTPU PU_SSCP 0 ACTIVE MANAGER.SYS OFF
XPORTLU LU_SSCP 1 ACTIVE MANAGER.SYS OFF
XPORTLU LU_SSCP 2 ACTIVE MANAGER.SYS OFF
XPORTLU LU_SSCP 3 ACTIVE MANAGER.SYS OFF
XPORTLU LU_SSCP 4 ACTIVE MANAGER.SYS OFF
XPORTLU LU_SSCP 5 ACTIVE MANAGER.SYS OFF
XPORTLU LU_SSCP 6 RESET MANAGER.SYS OFF
PFA2 DEP_LU 2 PEND_ACT_R PITEST.PUT21R40 NMTC0090.PUB.SYS
PFA3 DEP_LU 3 ACTIVE PITEST.PU2140 OFF
PFA4 DEP_LU 4 PEND_RST_R PITEST.PU2140 OFF
PFA5 DEP_LU 5 PEND_SON PITEST.PU2140 OFF
PFACLASS DEP_LU 1 RESET PITEST.PU2140 OFF
NAME TYPE LFSID STATE USER TRACE FILE
======== ======= ====== ========== =============== =========================
INDLU1 IND_LU 1,0200 PEND_ACT_L PITEST.PUT21R40 OFF
INDLU2 IND_LU 1,0201 PEND_RST_L PITEST.PUT21R40 OFF
INDLU3 IND_LU 1,0202 PEND_RST_N PITEST.PUT21R40 OFF
INDLU4 IND_LU RESET PITEST.PUT21R40 OFF
