SNA Link/iX Node Managers Guide (30291-90009)

Chapter 5 117
SNA Link Troubleshooting
Using NMDUMP for the SNA Links
Logging Records
Figure 5-4 is a partial example of the format for SDLC link logging
information.
Figure 5-4 SDLC Link Logging Format Example
SAT, Feb 29, 1992, 11:02:16.6 AM SDLC
Link (27)
Linkname = SDLC24 Event Type = Kill
Module
Log Class = Informational KM Version = A004005D
SAT, Feb 29, 1992, 11:03:05.2 AM SDLC
Link (27)
Linkname = SDLC24 Event Type = Module
Config
Log Class = Informational Path = 24
MC Version = A004005D
SAT, Feb 29, 1992, 11:03:07.3 AM SDLC
Link (27)
Linkname = SDLC24 Event Type = Driver
Startup
Log Class = Informational Driver Version = A004006A
Driver PDA Ptr = 0000000A.C2CC02C0
.
.
.
SAT, Feb 29, 1992, 11:31:58.7 AM SDLC
Link (27)
Linkname = SDLC24 Event Type = Kill
Module Error
Log Class = Error Path = 20
Error Num = #56 Status = CC9000D8
SAT, Feb 29, 1992, 11:33:09.4 AM SDLC
Link (27)
Linkname = SDLC24 Event Type = Driver
Error
Log Class = Error Location = $FF93
Sublocation = $0004 Error Code = #1016
Status = $9C9300D9 Cause Status = $9C9300D8
Error Actions = $000F
SAT, Feb 29, 1992, 11:33:44.8 AM SDLC
Link (27)
Linkname = SDLC24 Event Type = Module
Config Error
Log Class = Error Path = 20
Error Num = #16 Status = $9C9300D8
