SNA Link/iX Node Managers Guide (30291-90009)

114 Chapter5
SNA Link Troubleshooting
Using NMDUMP for the SNA Links
Figure 5-1 SNA Transport Trace Format Example
*************************************************************************
HP | EVENT : snasendexpedited call FEB 29, 1992, 8:27:43.022
HP | LU NAME : INDLU1 ROLE: Pri Session Type:
LU-LU IND
HP | Open ID : Not Used SIDH: nil SIDL: nil ODAI:
nil
HP | RESULT : Good Complete RU Length: 0020
HP | TH: SNF: 0001 Send ID: Not Used
HP | RH: REQ SC
FI.....BCI.ECI.DR1........................................
HP | RU: BIND 31 00 13 07 b0 b0 50 | ......&
HP | BUFFER: 31 00 13 07 b0 b0 50 b1 03 00 85 89 80 03 | ......&...ei..
HP | BUFFER: 06 02 00 00 00 00 00 00 00 00 00 00 00 00 | ..............
HP | BUFFER: 00 00 00 00 | ....
*************************************************************************
.
.
.
*************************************************************************
HP | EVENT : snarcv call FEB 29, 1992, 8:27:43.036
HP | LU NAME : INDLU1 ROLE: Pri Session Type:
LU-LU IND
HP | Open ID : Not Used SIDH: 02 SIDL: 00 ODAI:
01
HP | RESULT : Good Complete
*************************************************************************
.
.
.
*************************************************************************
IBM| EVENT : receive completion FEB 29, 1992, 8:27:43.046
IBM| LU NAME : INDLU1 ROLE: Pri Session Type:
LU-LU IND
IBM| Open ID : Not Used SIDH: 02 SIDL: 00 ODAI:
01
IBM| RESULT : RU Length: 0001
IBM| TH: Whole Expedited SNF: 0002 Send ID: Not Used
IBM| RH: +Rsp SC
FI.....BCI.ECI.DR1........................................
IBM| RU: UNBIND 32 | .
IBM| BUFFER: 2f 00 02 00 00 02 eb 80 00 32 | ..........
*************************************************************************
