SNA Link/iX Node Managers Guide (30291-90009)

Chapter 2 47
SNA Node and Link Configuration
NMMGR Configuration Overview
ID Blk: 023 ID Num: FFFF6 Max Data: 265 Type: X.25
LU Name LU# LU Name LU# LU Name LU# LU Name LU#
---- -- ---- -- ---- -- ---- --
LU01 1
X25LINK:
NS NI Name: ******** Inactivity Timeout: *****
VC Type: *** Call Direction: ***
Max Call Retries: *** Call Retry Delay: ***
PVC Number: **** Remote Address: ***************
-------------------------------------
Some fields could not be found or printed.
SNA/Token Ring Data
An example of a critical summary of SNA/Token Ring node and link
configuration is shown below.
CRITICAL SUMMARY - SNANODE CONFIGURATION
TUE, APR 20, 1993, 4:34 PM
CONFIGURATION FILE NAME: NMCONFIG.PUB.SYS
Validated subsystem.
SNANODE NAME: TRN3745
ID Blk: 2 ID Num: DCA12 Max Data: 017 Type: TOKEN
Node Type: 2.1 Node 2.1 Dependent LU Support: Y
LU Name LU# LU Name LU# LU Name LU# LU Name LU#
----
LU02 2 LU03 3
TOKEN Link:
Remote DSAP: 04 Retry Limit: 10
Local SSAP: 04 Acknowledgment Timer: 10
Unacknowledged Send Limit: 2 Error Timer: 100
Remote Station Address: 40-00-13-74-51-01
LINK NAME: TOKENLNK TYPE: TOKEN
Physical Path: 44
Buffer Size: 4096
Factory Configured address: Y
Local station address: FF-FF-FF-FF-FF-FF
-
Some optional or required fields are not configured.
