SNA Link/iX Node Managers Guide (30291-90009)

36 Chapter2
SNA Node and Link Configuration
Data Required from the Host Configuration
Table 2-4 shows the relationships between items from the host
configuration and items in the X.25 System Access configuration. The
HP SNA Products Remote System Configuration Guide explains the
host configuration. See the appropriate NS documentation for more
information about the X.25 System Access configuration.
Note that once the facility set to be used by SNA/X.25 Link is specified
in the INDEX operand of the X25.OUFT host macro, it must also be
referenced by the OUFINDX operand of the X25.LINE host macro.
Table 2-5 shows the relationship between items from the host
configuration and items in the DTC Manager configuration. The
HP SNA Products Remote System Configuration Guide explains the
host configuration. See the appropriate DTC documentation for more
information about the DTC Manager configuration through OpenView.
Table 2-3 Host Macro Values for X.25 Link SVC
Host Configuration
Macro nd Operand
Field in NMMGR Screen SNA Node NMMGR Screen
X25.LINE TYPE Virtual Circuit Type X.25 Link Data
CALL Call Direction X.25 Link Data
PATH DIALNO Remote’s X.25 Network
Address
X.25 Link Data
PU puname SNA Node Name Configuration
New Name Configuration
IDBLK ID BLK PU Data
IDNUM ID NUM PU Data
MAXDATA MAX DATA PU Data
LU luname LU Name LU Data
LOCADDR LU# LU Data
Table 2-4 Host Macro Values for X.25 System Access
Host Configuration Macro Field in NMMGR Screen Network Services
NMMGR Screen
X25.OUFT INDEX Set Name X.25 User Facility Sets
