SNA Link/iX Node Managers Guide (30291-90009)

146 Chapter6
MPE Commands
SNACONTROL STATUS
where IBMNODE is already active could generate this display:
Linkname: IBMNODE Linktype: SNA/SDLC Linkstate:
CONNECTING LEVEL 1
Physical Path 40
Phone Number
Auto Dial 0 Cable Type None
Station ID C1 Buffer Size 265 bytes
XID XID6789012 Connect Timeout 900 sec
Receive Timeout 180 sec Local Timeout 30 sec
Error Retries 7 Transmission Speed 9600 bps
Connect Duration 135:09:19 Tracing OFF
Data Bytes Sent 0 Data Bytes Rcvd 0
Overhead Bytes Sent 0 Overhead Bytes Rcvd 0
Total Frames Sent 0 Total Frames Rcvd 0
Data Frames Sent 0 Data Frames Rcvd 0
Bytes Retransmitted 0 Oversized Frames Rcvd 0
Frames Retransmitted 0 Aborted Frames Rcvd 0
DSR Losses 0 Receive Overruns 0
CTS Losses Unexpected 0 CRC Errors 0
DCD Carrier Losses 0 Statistics Resets 0
NAME TYPE NAU STATE USER TRACE FILE
======== ======= ====== ========== =============== =========================
XPORTPU PU_SSCP 0 ACTIVE MANAGER.SYS OFF
XPORTLU LU_SSCP 1 ACTIVE MANAGER.SYS OFF
XPORTLU LU_SSCP 2 ACTIVE MANAGER.SYS OFF
XPORTLU LU_SSCP 3 ACTIVE MANAGER.SYS OFF
XPORTLU LU_SSCP 4 ACTIVE MANAGER.SYS OFF
XPORTLU LU_SSCP 5 ACTIVE MANAGER.SYS OFF
XPORTLU LU_SSCP 6 RESET MANAGER.SYS OFF
PFA2 DEP_LU 2 PEND_ACT_R PITEST.PUT21R40 NMTC0090.PUB.SYS
PFA3 DEP_LU 3 ACTIVE PITEST.PU2140 OFF
PFA4 DEP_LU 4 PEND_RST_R PITEST.PU2140 OFF
PFA5 DEP_LU 5 PEND_SON PITEST.PU2140 OFF
PFACLASS DEP_LU 1 RESET PITEST.PU2140 OFF
NAME TYPE LFSID STATE USER TRACE FILE
======== ======= ====== ========== =============== =========================
INDLU1 IND_LU 1,0200 PEND_ACT_L PITEST.PUT21R40 OFF
INDLU2 IND_LU 1,0201 PEND_RST_L PITEST.PUT21R40 OFF
INDLU3 IND_LU 1,0202 PEND_RST_N PITEST.PUT21R40 OFF
INDLU4 IND_LU RESET PITEST.PUT21R40 OFF
Terminology The linkname is the same as the node name.
The linktype is “SNA/SDLC”.
The linkstate is one of the following:
• NOT CONNECTED = The connection is closed.
• CONNECTED LEVEL1=Alevel 1 connection has been established.
