SNA Node and Link Configuration
Configuring the SNA Node and Link
AS/400 Configuration: The DSAP in the controller
description for the HP 3000 must match this field; see
Table 2-10.
NOTE A service access point (SAP) pair identifies a MAC type 2 connection.
This pair consists of two SAPs: the destination SAP (DSAP) and the
local SAP (LSAP). DSAP is the SAP of the remote computer and LSAP
is the SAP of the local computer. The SAP pair, along with the remote
and local station address, uniquely identifies a logical connection in the
token ring network.
Unacknowledged Send Limit
Required. The maximum number of frames that a
MAC type 2 connection expects to receive before
sending an acknowledgment.
Range: 1-127 (integer)
Default: 2
Retry Limit
Required. The maximum number of times a MAC
type 2 connection retransmits a frame before dropping
the connection.
Range: 1-254 (integer)
Default: 10
Acknowledgment Timer
Required. The maximum time, in tenths of a second,
that the MAC type 2 connection waits before
determining that a frame has been dropped and
retransmitting.
Range: 1-254 (integer)
Default: 10 (1 second)
Error Timer
Required. The amount of time, in tenths of a second,
that the MAC type 2 connection waits before initiating
a Poll/Find (P/F) cycle.
Range: 1-600 (integer)
Default: 100 (10 seconds)
