SNA Link/iX Node Managers Guide (30291-90009)

Chapter 2 39
SNA Node and Link Configuration
Data Required from the AS/400 Configuration
Data Required from the AS/400 Configuration
Data in an SNA node configuration file must correspond to information
from the remote AS/400 type 2.1 parameters. So, before using NMMGR,
you should have certain information from the AS/400 configuration.
The AS/400 information that corresponds to SNA node configuration
information for SNA/SDLC links, SNA/X.25 links, and SNA/Token Ring
links is described below.
SNA/SDLC Information
For the AS/400 and the HP 3000 to communicate, you must coordinate
the SNA/SDLC node configuration with the AS/400 configuration. The
HP SNA Products Remote System Configuration Guide explains this
configuration.
Table 2-8 shows the relationships between parameters from the AS/400
configuration and items in the SNA node configuration file for an
SNA/SDLC link. Each NMMGR screen field is described later in this
chapter.
SNA/X.25 Information
For the AS/400 and the HP 3000 to communicate, you must coordinate
the SNA/X.25 node configuration with the AS/400 configuration. The
HP SNA Products Remote System Configuration Guide explains this
configuration.
Table 2-9 shows the relationships between parameters from the AS/400
configuration and items in the SNA node configuration file for switched
virtual circuits (SVCs) of an SNA/X.25 link. Each NMMGR screen field
is described later in this chapter.
Table 2-8 AS/400 Parameter Values for SDLC Link
AS/400 Configuration Parameter Field in NMMGR Screen NMMGR Screen
Name
MAXFRAME in the line description MAX DATA PU Data
LINESPEED in the line description Transmission Speed SDLC Link Data
EXCHID in the controller description ID BLK combined with ID NUM PU Data
STNADR in the controller description Station ID SDLC Link Data
RMTLOCNAME in the device description LU Name LU Data
