SNA Link Troubleshooting

Using NMDUMP for the SNA Links

X.25 Link Output Formats

For the X.25 link, NMDUMP formats tracing records. (Logging

information is contained within the SNA Transport logging

information.) When NMDUMP displays the list of subsystems and IDs,

and prompts you for the IDs you want to select, specify the ID for X.25

Link: 38. Then, proceed normally with NMDUMP. The format of the

tracing records is shown below.

Tracing Records

Figure 5-5 is a partial example of the format of a tracing record for the

X.25 link.

Figure 5-5 X.25 Link Tracing Record Format Example

Logging Records

As stated earlier in this chapter, X.25 link logging information is

contained within the SNA Transport logging information.

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!

HP | EVENT: Snax25_module_config Call FEB 29, 1992, 3:47:47.033

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!

HP | EVENT: QLLC Initialization Begins FEB 29, 1992, 3:47:48.040

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!

HP | EVENT: IPCCREATE Call FEB 29, 1992, 3:47:48.045

HP | RESULT: GOOD COMPLETE

HP | DESC: X 0000000A

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!

HP | EVENT: IPCDEST Call FEB 29, 1992, 3:47:48.053

HP | RESULT: GOOD COMPLETE

HP | DESC: X FFFFFFFF

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!

HP | EVENT: IPCCONNECT Call FEB 29, 1992, 3:47:49.010

HP | RESULT: GOOD COMPLETE

HP | CALL DESC: X 0000000A

HP | VC DESC: X 0000000B

HP | DEST DESC: X FFFFFFFF

!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
